Perlan 140 wood * Sliding door fitting system for timber, plastic, or metal doors with a leaf weight of 140 kg

Perlan 140
  • Sliding door fitting for leaf weights of up to 140 kg
  • For leaves made of wood, plastic, or metal
  • With one or tow-sided draw-in damper
  • Adjustable height compensation levels out unevenness between the ceiling and the track
  • Precision ball bearings in the roller carriages offer very smooth sliding action
  • Tested for durability in accordance with DIN EN 1527 over 100,000 test cycles
Show more
  • Retractable suspension plates allow for the door to be installed with a small clearance between the track and the upper edge of the door
Contact us

Application Areas

  • Frequently used interior sliding doors
  • Living, office, and conference areas as well as hotels
  • Installation of fittings in all visible areas
  • Single and multiple-leaf sliding doors

Technical data

Perlan 140 wood
Leaf material Wood, Metal
Leaf weight (max.) 140 kg
Number of leaves 1-leaf
Leaf width (min.) 500 mm
Leaf width (max.) 1640 mm
Leaf height (max.) 3500 mm
Leaf thickness from 22 mm
Leaf thickness to 40 mm
Track geometry straight
EN 1670 Corrosion resistance 2 (acc. to EN 1670: Class 0 = none defined, Class 1 = low, Class 2 medium, Class 3 = high, Class 4 = very high, Class 5 = extraordinary)
EN 1527 Continuous function 100,000 test cycles
Type of installation Wall, Ceiling
DIN direction left / right
Manual operation Yes
Surface anodised
Colour EV1


GEZE Central 900-730-440 GEZE Service 900-730-442
